產品特性:
●D型：拉桿、凸輪鎖定連接Form D(Mounting with Studs and locknuts)
產品詳情
■尺寸、性能參數 Dimension Characteristic Parameters
|
型號規格
Model
|
D
|
D1
|
D2
|
D3
|
D4
|
H1
|
h
|
h1
|
z-d
|
凈重kg
Net WT.
|
|
125/D3
|
125
|
53.975
|
70.6
|
25
|
92
|
63
|
13
|
10
|
3-M10×1
|
-
|
|
125/D4
|
125
|
63.513
|
82.6
|
25
|
117
|
63
|
13
|
10
|
3-M10×1
|
-
|
|
160/D3
160A/D3
|
160
|
53.975
|
70.6
|
40
|
92
|
76
|
13
|
10
|
3-M10×1
|
10
|
|
160/D4
160A/D4
|
160
|
63.513
|
82.6
|
40
|
117
|
70
|
13
|
10
|
3-M10×1
|
10
|
|
160/D5
160A/D5
|
160
|
82.563
|
104.8
|
40
|
146
|
73
|
15
|
12
|
6-M12×1
|
10
|
|
200/D4
200C/D4
200A/D4
|
200
|
63.513
|
82.6
|
50
|
117
|
86
|
13
|
10
|
3-M10×1
|
17
|
|
200/D5
200C/D5
200A/D5
|
200
|
82.563
|
104.8
|
50
|
146
|
86
|
15
|
12
|
6-M12×1
|
17
|
|
200/D6
200C/D6
200A/D6
|
200
|
106.375
|
133.4
|
50
|
181
|
86
|
16
|
13
|
6-M16×1.5
|
17
|
|
250/D5
250C/D5
250A/D5
|
252
|
82.563
|
104.8
|
70
|
146
|
95
|
15
|
12
|
6-M12×1
|
31
|
|
250/D6
250C/D6
250A/D6
|
252
|
106.375
|
133.4
|
70
|
181
|
98
|
16
|
13
|
6-M16×105
|
32
|
|
250/D8
250C/D8
250A/D8
|
252
|
139.719
|
171.4
|
80
|
225
|
98
|
18
|
14
|
6-M20×1.5
|
32
|
|
325/D6
325C/D6
325A/D6
|
325
|
106.375
|
133.4
|
100
|
181
|
103.5
|
16
|
13
|
6-M16×1.5
|
51
|
|
325/D8
325C/D8
325A/D8
|
325
|
139.719
|
171.4
|
105
|
225
|
103.5
|
18
|
14
|
6-M20×1.5
|
51
|
|
325/D11
325C/D11
325A/D11
|
325
|
196.869
|
235
|
105
|
298
|
103.5
|
20
|
16
|
6-M22×1.5
|
53
|
|
380/D8
380C/D8
380A/D8
|
380
|
139.719
|
171.4
|
130
|
225
|
118
|
18
|
14
|
6-M20×1.5
|
81
|
|
380/D11
380C/D11
380A/D11
|
380
|
196.869
|
235
|
135
|
298
|
118
|
20
|
16
|
6-M22×1.5
|
81
|
|
500D/D11
|
500
|
196.869
|
235
|
190
|
298
|
135
|
20
|
16
|
6-M22×1.5
|
159
|
|
500D/D15
|
500
|
285.775
|
330.2
|
210
|
403
|
135
|
21
|
17
|
6-M24×1.5
|
159
|
|
630/D11
|
630
|
196.869
|
235
|
190
|
298
|
150
|
20
|
16
|
6-M22×1.5
|
159
|
|
630/D15
|
630
|
285.775
|
330.2
|
210
|
403
|
150
|
21
|
17
|
6-M24×1.5
|
159
|
|
|
|
|
|
|
 |
|
